Stage 260W

The JBL Stage 260W delivers high-quality JBL audio in a discreet in-wall design. Equipped with a 6.5-inch (165mm) Polycellulose cone woofer and a 1-inch (25mm) aluminum dome tweeter with HDI™ waveguide, it provides balanced sound with deep bass, smooth midrange, and accurate high-frequency response.

Specifications

• Brand: JBL
• Model: Stage 260W (JBL260W)
• Type: 2-Way In-Wall Loudspeaker
• Woofer: 6.5-inch (165mm) Polycellulose Cone Woofer
• Tweeter: 1-inch (25mm) Aluminum Dome Tweeter with HDI™ Waveguide
• Frequency Response: 50Hz – 25kHz (-6dB)
• Recommended Amplifier Power: 20W – 100W RMS
• Sensitivity: 87dB (2.83V/1m)
• Nominal Impedance: 8 Ohms
• Crossover Frequency: 1900Hz
• Inputs: Nickel-Plated Spring-Loaded Connectors
• Grille Dimensions: 33.9 × 21.7 cm (H × W)
• Cutout Dimensions: 31.1 × 18.4 cm (H × W)
• Mounting Depth: 9.2 cm
• Product Weight: 2.2 kg
• Installation Type: In-Wall Mount
• Grille Type: Zero-Bezel Magnetic Grille
