Emotiva XPA-9 Gen3 9 Channel Audiophile Home Theater Power Amplifier

Brand: Emotiva | Model: N/A

✗ Out of Stock

₹406,412.50 ₹416,412.50 2% OFF

(Incl. of all taxes)

WhatsApp Enquiry

Check Delivery Options & Time

🚛 Standard (By Road) ✈️ Express (By Air)

100% Original

Genuine Products

GST Invoice

Available

Fast Delivery

Safe & Secure

Description
Specifications
Reviews (0)

The Emotiva XPA-9 Gen3 is a flagship 9-channel audiophile power amplifier engineered to deliver reference-grade performance for premium home theater and multi-channel music systems. Built on Emotiva's renowned Gen3 modular platform, it combines high-current Class A/B amplifier modules, a high-efficiency audiophile-grade Switch Mode Power Supply (SMPS), and Optimized Class H™ power supply technology to provide exceptional dynamics, low distortion, and outstanding speaker control.

The XPA-9 Gen3 is uniquely configured with five high-powered mono amplifier modules and two stereo amplifier modules, making it an ideal solution for 7.1.2 Dolby Atmos, 5.1.4 Dolby Atmos, DTS:X, or multi-zone home theater systems. The high-power channels drive the front and surround speakers with exceptional authority, while the stereo modules efficiently power height or rear surround channels, ensuring balanced performance throughout the entire soundstage.

Each high-powered channel delivers 300 Watts RMS into 8 ohms and 490 Watts RMS into 4 ohms (two channels driven), while each stereo module provides 65 Watts RMS into 8 ohms and 100 Watts RMS into 4 ohms. The amplifier features fully discrete dual-differential Class A/B circuitry, balanced XLR and unbalanced RCA inputs, premium gold-plated 5-way speaker binding posts, and intelligent microprocessor-controlled protection circuitry for reliable long-term operation.

Designed and assembled in the USA, the XPA-9 Gen3 offers exceptional build quality, future-ready modular architecture, and the power required to reproduce today's demanding movie soundtracks and high-resolution music with remarkable realism.

Key Features

9-Channel Audiophile Home Theater Power Amplifier
Modular XPA Gen3 Architecture
Five High-Power Mono Amplifier Modules
Two Stereo Amplifier Modules
Fully Discrete Dual-Differential Class A/B Amplifier Design
Audiophile-Grade Switch Mode Power Supply (SMPS)
Optimized Class H™ Power Supply Technology
300W RMS @ 8Ω (High-Power Channels)
490W RMS @ 4Ω (High-Power Channels)
65W RMS @ 8Ω (Stereo Module Channels)
100W RMS @ 4Ω (Stereo Module Channels)
Balanced XLR & Unbalanced RCA Inputs
Gold-Plated 5-Way Speaker Binding Posts
Microprocessor-Controlled Protection System
12V Trigger Input & Output
Designed, Assembled & Tested in the USA

Technical Specifications

Specification	Details
Product Type	9-Channel Power Amplifier
Brand	Emotiva
Model	XPA-9 Gen3
Amplifier Class	Class A/B
Amplifier Topology	Fully Discrete Dual Differential
Channels	9
Configuration	5 High-Power Mono Modules + 2 Stereo Modules
High-Power Channel Output (8Ω)	300W RMS/Channel
High-Power Channel Output (4Ω)	490W RMS/Channel
Stereo Module Output (8Ω)	65W RMS/Channel
Stereo Module Output (4Ω)	100W RMS/Channel
Power Supply	High-Efficiency Audiophile SMPS
Power Topology	Optimized Class H™
Frequency Response (High-Power Modules)	5Hz – 80kHz (+0 / –2dB)
Frequency Response (Stereo Modules)	50Hz – 80kHz (+0 / –1.5dB)
Power Bandwidth	20Hz – 20kHz (+0 / –0.1dB)
THD + Noise (High-Power Modules)	<0.005% @ 100W, 1kHz
THD + Noise (Stereo Modules)	<0.02% @ 60W, 1kHz
Signal-to-Noise Ratio	>115dB (High-Power Modules)
Damping Factor	>500
Gain	29dB
Input Sensitivity	1.71V (High-Power Modules), 0.8V (Stereo Modules)
Input Impedance	33kΩ (Balanced), 23.5kΩ (Unbalanced)
Inputs	9 × Balanced XLR, 9 × RCA
Speaker Outputs	Gold-Plated 5-Way Binding Posts
Trigger Input	5–12V AC/DC
Trigger Output	12V DC (120mA Max)
Protection	Thermal, Short Circuit, Ground Fault & Overload
Power Requirement	100–250V AC, 50/60Hz (Auto Switching)
Maximum Power Consumption	2,600W
Dimensions (W × H × D)	432 × 203 × 483 mm (17 × 8 × 19 in)
Weight	24 kg (53 lbs)
Finish	Black with CNC-Machined Aluminum Front Panel
